What You Need To Know About Wire Color Codes?

Do you ever think that we should learn about radio wire color codes?

I never thought that until about a month ago, when my mother asked me to fix her old car radio. I did not remember precisely how I reacted but the whole process was a disaster.

The reason was I did not know which wire should be hooked up in another; or more precisely, I could not recall any of radio wire color codes. And it didn’t have a harness as well, which made the wires even more confused and everything went ultimately messed up. Therefore, it took me a half of the morning to finish the job and help my mother have brand new cables.

It was not a difficult job but truly made me realize how important we needed to remember wire color codes. And I know that many of people, including you, have not discovered why we need to know about them and what the feature of each wire is. So in this article today, I will show you the most basic things you need to know about them. If you are having any problems just like mine, I believe it would help you.

1. What are the wires color codes?

Some basic codes are approved in many countries and almost all of brands of cars and radios. I will mention about some different codes other vehicles in the next parts. For now, you won’t need to wonder if there would be any distinctions in each type.

Following table and installing your radio won’t be such a hard work anymore


You can watch this video for more explanation:


2. Why do we need them?

We need the wire codes mostly for emergencies. My situation is one example, which I needed to repair my mother’s aftermarket radio and didn’t want to waste time searching Google. Learning the functions of each wire saved me quite a lot of money for technical guys, who never undercharge. And if you memorize them, you won’t need so much time like me to find out which wires need being connected with each other. The entire installing process would be very smooth and comfortable.

Besides, you will also know why we need different color codes if you discover a little about their origins. I guess hardly anyone knows that the wires did not have as many colors as they are now. The original ones started being used when Thomas Edison commercialized light bulbs more than a century ago, which were only made with three basic colors: Black, Gray, and Red. Radio wires were invented about 50 years after that and could not avoid being made with the same format.

Therefore, if you ever find a radio with one three colors that I have mentioned above, you should not use it. I’m sure it was made over 30 years ago and would not meet any electrical safety requirements that are set up at the present.


Car Stereo Wiring Explained In Detail


3. Some other color codes

BMW Cars:

Wires Colors Functions
Power cable Violet Control the switch, which turns the radio on and off
Ground cable Brown Connect your radio desk with amplifier and adjust the current
Constant Power Cable Gray with stripe Red Keep the battery in stable condition
Amp turn on wire White Work as an antenna and adjust the signal
Illumination White with stripe Blue Increase the light of the radio screen
Dimmer Not used
Speaker wire Gray with stripe Red Front left speaker
Speaker wire Gray with stripe Violet Front left speaker
Speaker wire Gray with stripe White Front right speaker
Speaker wire Gray with stripe Brown Front right speaker
Speaker wire Black with stripe Red Rear left speaker
Speaker wire Black with stripe Violet Rear left speaker
Speaker wire Black with stripe White Rear right speaker
Speaker wire Black with stripe Brown Rear right speaker


Ford Cars:

Wires Colors Functions
Power cable Yellow with stripe Black Control the switch, which turns the radio on and off
Ground cable Black or Red Connect your radio desk with amplifier and adjust the current
Constant Power Cable Green with stripe Yellow Keep the battery in stable condition
Amp turn on wire Blue Work as an antenna and adjust the signal
Illumination Orange Increase the light of the radio screen
Dimmer Orange with stripe White Decrease the light of the radio screen
Speaker wire Orange with stripe Green Front left speaker
Speaker wire Light Blue Front left speaker
Speaker wire White with stripe Green Front right speaker
Speaker wire Green with stripe Orange Front right speaker
Speaker wire Pink with stripe Green Rear left speaker
Speaker wire Pink with stripe Blue Rear left speaker
Speaker wire Pink with stripe Blue Rear right speaker
Speaker wire Green with stripe Orange Rear right speaker


Mazda Cars:

Wires Colors Functions
Power cable Blue with stripe White Control the switch, which turns the radio on and off
Ground cable Black Connect your radio desk with amplifier and adjust the current
Constant Power Cable Blue with stripe Red Keep the battery in stable condition
Amp turn on wire Blue Work as an antenna and adjust the signal Some wires need a relay due to a negative terminal trigger
Illumination Red with stripe Black Increase the light of the radio screen
Dimmer Not used
Speaker wire Blue Front left speaker
Speaker wire Blue with stripe White Front left speaker
Speaker wire Blue with stripe Red Front right speaker
Speaker wire Blue with stripe Orange Front right speaker
Speaker wire Blue with stripe White Rear left speaker
Speaker wire Blue with stripe Green Rear left speaker
Speaker wire Blue with stripe Orange Rear right speaker
Speaker wire Blue with stripe Black Rear right speaker


Conclusion

Regardless, thank you for reading my article about radio wire color codes. I hope you have had a great time with it and if you have any opinions or questions, do comment. I would love to reply. Goodbye, and I look forward to see you in my subsequent writings.
